Montmartre H128 French Retro Window
The Montmartre H128 French Retro Window with Integrated Screen combines classic French style with modern technology, redefining the aesthetics and functionality of windows. Made from 6063-T6 titanium-magnesium alloy and featuring 5G+14A+5G tempered insulated double white glass, it enhances sound insulation, thermal insulation, and waterproofing. The integrated screen design offers options for inward-opening or retractable screens, blending practicality with romantic charm.
Supply Ability: 50000 ㎡ per year
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time: 60 days
Packaging Details: Carton or wooden case
Price: Negotiable
Minimum Order Quantity: Negotiable
Model Number: roller shutter
Certification: AS 2047
Brand Name: M&L
Place Of Origin: China
| Air Tightness Performance | level 6 | (AAMA Standard) |
| Water Tightness Performance | level 5 680Pa | (AAMA Standard) |
| Wind Resistance Performance | level 7 | (AAMA Standard) |
| Thermal Insulation Performance | level 8 | (GBT8478) |
| Sound Insulation Performance | level 4 | (GBT8478) |
| Main Profile Wall Thickness (mm) |
Visible Surface Dimensions (mm) |
Profile Thickness Dimensions (mm) |
Glass Thickness (mm) |
Thermal Break (mm) |
Sash Width: 400mm-800mm |
||
|
frame：2.2 |
Frame: 22 |
Sash: 45 |
Frame:128 |
5G+16A+5G |
25 |
Sash Height: 400mm-1600mm |
|
|
Sash: 70.2 |
|||||||
|
Mid Frame: 22 |
screen Sash: 70.2 |
screen Sash: 70.2 |
Maximum Sash Weight: 60kg |
||||
Style
● Using 6063-T6 titanium-magnesium alloy primary aluminum, the main profile wall thickness is 2.2mm.
● French design concept, with our company's redesign and improvement of the plastic structure, preserving the original style of traditional French steel windows while enhancing the overall 6 major performance aspects of the window.
● Standard configuration includes 5G+14A+5G tempered insulated double Ultra Clear glass, with the hollow aluminum strip and grid strip corresponding to each other.External three-dimensional double-sided decorative grid strips, presenting an overall appearance of French style and romantic charm.
● Equipped with 25mm multi-chamber PA66F25 thermal insulation nylon strip, improving the window's sound insulation, thermal insulation, and overall performance.
● Triple sealing, vertical isothermal line improvement, and EPDM composite sealing strips enhance waterproofing, sound insulation, thermal insulation, and overall performance.
● The Montmartre H128 series is derived from our Athens H70A series, with further modifications to create a French retro steel window with integrated screen. The screen sash can be chosen as inward-opening or retractable.
● Optional hardware configurations: pure copper linked double-point handle, pure copper single-point handle
