Montmartre M128 French Retro-Style Thermal Break Door with Integrated Screen
This door/window series features a rectangular 5-chamber frame and stile structure, combined with injection-molded corner brackets and multi-functional connectors to ensure structural stability. The exclusive embedded 3D glazing beads, available in three sizes for oversized glass panels, enhance installation efficiency and minimalist aesthetics. Full exterior EPDM gaskets and interior-side glazing beads eliminate leakage risks while improving airtightness, thermal insulation, and soundproofing. A mid-sealed sub-frame design optimizes installation control, and flush indoor-outdoor surfaces conceal gaps for seamless visuals. High-load-bearing hinges (60kg capacity per hinge) and multi-point locking mechanisms guarantee security and durability. An exposed drainage system with windproof covers prevents backflow, ensuring efficient water management.
Supply Ability: 50000 ㎡ per year
Payment Terms: L/C, D/A, D/P, T/T, Western Union, Money Gram
Delivery Time: 60 days
Packaging Details: Carton or wooden case
Price: Negotiable
Minimum Order Quantity: Negotiable
Model Number: french style window
Certification: AS 2047
Brand Name: M&L
Place Of Origin: China
| Air Tightness Performance | level 7 | (AAMA Standard) |
| Water Tightness Performance | level 6 720Pa | (AAMA Standard) |
| Wind Resistance Performance | level 7 | (AAMA Standard) |
| Thermal Insulation Performance | level 8 | (GBT8478) |
| Sound Insulation Performance | level 4 | (GBT8478) |
|
Main Profile Wall Thickness (mm) |
Visible Surface Dimensions (mm) |
Profile Thickness Dimensions (mm) |
Glass Thickness (mm) |
Thermal Break (mm) |
Sash Width: 1000mm-5000mm |
||
|
external frame:2.2 Sash:3.3 |
Frame: 120 |
Sash: 50 |
Frame: 165 |
5G+16A+5G |
14.8 |
Sash Height: 800mm-1500mm |
|
|
Sash:103 |
|||||||
|
Screen Sash: 64 |
Maximum Sash Weight: 250kg |
||||||
Style
● Handrail surface width: 14.5 cm
● When closed, forms an ultra-wide wind pressure-resistant cross-section
● Standard glass configuration: 6G Ultra clear glass + 20A + 6G Ultra clear glass insulated tempered glass
● Fixed sash position can be equipped with an intelligent lift screen window
● Uses a thermal break system to maintain indoor temperature and provide excellent sound insulation
● Equipped with functional control panel, remote control, mobile app, and AI voice control system
● Optional backup battery for a more worry-free life
