Tilt and Turn Windows
86 Series Minimalist Ultra-Slim Tilt and Turn Windows ( slim profile )
Maximum/Minimum Dimensions of Operable Sash (Width & Height) (mm)
Maximum Size:1000*2600
Minimum Size: 505*640
Accessories: Belgium Sobinco
Visible Dimensions Calculation Rules for Fenestration Products
Edge to Edge: 83mm
Edge to Centerline: 75.95mm
Centerline to Centerline: 68.9 mm
Standard Glazing Specifications
5G+18A+5G
5G+12A+5G+12A+5G
Maximum Clear Rebate of Frame & Sash: 61mm
Max. Frame/Sash Clear Rebate: 52mm
Note: The tilt ventilation capacity of the product is determined by the selected hardware brand and the width of the operable sash.
86 Series Minimalist Ultra-Slim Tilt and Turn Windows ( wide profile )
Maximum/Minimum Dimensions of Operable Sash (Width & Height) (mm)
Maximum Size: 1000*2600
Minimum Size: 525*670
Accessories: Belgium Sobinco
Visible Dimensions Calculation Rules for Fenestration Products
Edge to Edge: 112mm
Edge to Centerline: 90.45mm
Centerline to Centerline: 68.9mm
Standard Glazing Specifications
5G+18A+5G
5G+12A+5G+12A+5G
Maximum Clear Rebate of Frame & Sash: 61mm
Max. Frame/Sash Clear Rebate:52mm
Note: The tilt ventilation capacity of the product is determined by the selected h ardware brand and the width of the operable sash.
M Series
M Series represents a latest in design, building upon the prototype to meet the demand of architects for a minimalist and seamless glass facade. With its sleek integration of glass and frame, it achieves a harmonious balance between functionality and aesthetic appeal.
86-M Series Minimalist Ultra-Slim Tilt and Turn Windows
Maximum/Minimum Dimensions of Operable Sash (Width & Height) (mm)
Maximum Size: 1000*2600
Minimum Size: 505*640
Accessories: Belgium Sobinco
Visible Dimensions Calculation Rules for Fenestration Products
Edge to Edge: 84mm
Edge to Centerline: 76.5mm
Centerline to Centerline: 68.9mm
Standard Glazing Specifications
5G+18A+5G
5G+27A+5G
Maximum Clear Rebate of Frame & Sash: 61mm
Max. Frame/Sash Clear Rebate: 38mm
Note: The tilt ventilation capacity of the product is determined by the selected h ardware brand and the width of the operable sash.
131-M Series Minimalist Ultra-Slim Tilt and Turn Windows
Maximum/Minimum Dimensions of Operable Sash (Width & Height) (mm)
Maximum Size:1000*2600
Minimum Size: 505*640
Accessories: Belgium Sobinco
Visible Dimensions Calculation Rules for Fenestration Products
Edge to Edge: 122mm
Edge to Centerline: 100.45mm
Centerline to Centerline: 78.9 mm
Standard Glazing Specifications
5G+18A+5G
5G+27A+5G
5G+9A+5G+9A+5G
Maximum Clear Rebate of Frame & Sash: 61mm
Max. Frame/Sash Clear Rebate: 38mm
Y Series
86-Y Series Minimalist Ultra-Slim Tilt and Turn Windows
86-Y Series Minimalist Ultra-Slim Tilt and Turn Windows
Maximum/Minimum Dimensions of Operable Sash (Width & Height) (mm)
Maximum Size: 1000*2600
Minimum Size: 505*640
Accessories: Belgium Sobinco
Visible Dimensions Calculation Rules for Fenestration Products
Edge to Edge: 120.6mm
Edge to Centerline: 113.5mm
Centerline to Centerline: 106.5mm
Standard Glazing Specifications
5G+18A+5G
8G+27A+8G
Maximum Clear Rebate of Frame & Sash: 49mm
Max. Frame/Sash Clear Rebate: 49.7mm
Note: The tilt ventilation capacity of the product is determined by the selected h ardware brand and the width of the operable sash.
YS Series
YS Series is an elevated design derived from the prototype, incorporating an integrated fly screen for a seamless and secure solution. With its slim frame design, it ensures both high transparency and protection against insects, using a stainless-steel mesh that can be opened, removed, and equipped with a child safety lock. Additionally, the option to add an external invisible railing，provides triple security measures. This series is perfect for projects requiring elevated safety and insect protection in high-rise settings as well as individual homes.
YS Series Minimalist Ultra-Slim Tilt and Turn Windows
Maximum/Minimum Dimensions of Operable Sash (Width & Height) (mm)
Maximum Size: 700*1600
Minimum Size: 505*640
Accessories: Belgium Sobinco
Standard Glazing Specifications
5G+18A+5G
5G+9A+5G+9A+5G
Maximum Clear Rebate of Frame & Sash: 49mm
Max. Frame/Sash Clear Rebate: 36mm
Note: The tilt ventilation capacity of the product is determined by the selected h ardware brand and the width of the operable sash.
